Plastic Shredder/Plastic cans/ Waste Plastic shredder
machine/Plastic Scrap recycling machine :
The Plastic Shredder/Plastic Cans shredder machine/Plastic Scrap
recycling machine have been design for a wide array of applications
and industries, suitable for shredding solid material such as car
tire, truck tire, e-waste, metal, wood,plastic, scrap tires,
packaging barrel, pallets, etc. Depending on input material and the
following process the shredded material can be used directly or go
into the next step of size reduction. It is widely used in industry
waste recycling, medical recycling, electronic recycling, pallet
recycling, municipal solid waste recycling, plastic recycling, tire
recycling, papermaking industry and etc.
Zibo United Tech Machiner Co., Ltd. ---
Plastic Shredder/Plastic Cans shredder/Plastic Scrap recycling
machine series has two rotors built into the machine that rotate at low speeds, high torque and low noise. Adopt
microcomputer control system with function of start, stop,
automatic reverse sensors to protect the machine against over
loading and jamming.
Our service:
(1) Your inquiry related to our products or prices will be replied
in 24hours.
(2) Our engineer will make machine placement chart according to
client’s workshop chart
(3) We provide 12 months guarantee since the date of bill of
loading. All products are passed strict test.
Plastic Shredder/Plastic Cans shredder machine/Plastic Scrap
recycling machine Application:
The Plastic Shredder / Plastic Cans shredder machine/ Plastic Scrap recycling machine is suitable for
crushing the big solid material like paper tube, wood tube, fishing
net, pipe fittings, forklift splint, tyres, packing barrel, vehicle
body, aluminum, copper and steel less than 10mm.
Double shaft shredder have been designed for a wide array of applications and
industries, suitable for shredding solid material such as E-waste,
metal, wood, plastic, scrap tires, packaging barrel. Pallets, etc.
And particularly well suited to the size reduction of bulky or
voluminous materials which could include contamination such as
metals or stones. Depending on input material and the following
process the shredded material can be used directly or go into the
next step of size reduction. It can efficient to increase the bulk
density and decrease the transportation cost. It is widely used in
industry waste recycling, medical recycling, electronic recycling,
pallet recycling, municipal solid waste recycling, plastic
recycling, tire recycling, paper making industry, etc.
Double Shaft Shredder has two rotors built into the machine that rotate at low speeds,
high torque and low noise. With the function of Siemens
microcomputer control system, it is possible to control
automatically start, stop. Automatic reverse sensors to protect the
machine against over loading and jamming.
Mode | D2830 | D2840 | D2860 | D2880 |
dimension L/W/H(mm) | 1450x1060x1850 | 1590x1060x1850 | 2560x1060x1850 | 2820x1060x1850 |
Cutting Chamber size C/D(mm) | 300x470 | 400x470 | 600x480 | 800x480 |
Rotor Blade Diameter(mm) | Φ280 | Φ280 | Φ280 | Φ280 |
Rotor Ratate Speed (r/min) | 14.2 | 14.2 | 14.2 | 14.2 |
Rotor Blade Quantity (PCS) | 15 | 20 | 30 | 40 |
Rotor Blade Thickness(mm) | 20 | 20 | 20 | 20 |
Rotor Motor Powder(KW) | 7.5 | 7.5 | 5.5+5.5 | 7.5+7.5 |
Net Weight(KG) | 1300 | 1450 | 2000 | 2200 |
|
|
|
|
|
Model | D3260 | D3280 | D4280 | D42100 |
dimension L/W/H(mm) | 2658x1366x1911 | 2930x1385x1927 | 2940x1816x2270 | 3275x1946x2275 |
Cutting Chamber size C/D(mm) | 610x580 | 890x580 | 890x736 | 1052x736 |
Rotor Blade Diameter(mm) | Φ320 | Φ320 | Φ430 | Φ430 |
Rotor Ratate Speed (r/min) | 14.2 | 14.2 | 14.8 | 14.8 |
Rotor Blade Quantity (PCS) | 20 | 22 | 22 | 26 |
Rotor Blade Thickness(mm) | 30 | 40 | 40 | 40 |
Rotor Motor Powder(KW) | 15 | 18.5 | 15+15 | 18.5+18.5 |
Net Weight(KG) | 2200 | 2400 | 3700 | 4100 |
|
|
|
|
|
Model | D42120 | D52100 | D52130 | D52160 |
dimension L/W/H(mm) | 3416x1946x2275 | 3334x1866x2670 | 3716x2234x2670 | 4016x2234x2670 |
Cutting Chamber size C/D(mm) | 1213x736 | 984x948 | 1324x948 | 1624x948 |
Rotor Blade Diameter(mm) | Φ430 | Φ514 | Φ514 | Φ514 |
Rotor Ratate Speed (r/min) | 14.8 | 11.8 | 11.8 | 11.8 |
Rotor Blade Quantity (PCS) | 30 | 20 | 26 | 32 |
Rotor Blade Thickness(mm) | 40 | 50 | 50 | 50 |
Rotor Motor Powder(KW) | 22+22 | 30+30 | 37+37 | 45+45 |
Net Weight(KG) | 4500 | 6500 | 8700 | 9200 |
