The cable and wire is made of cooper or alumina. So it is high
value about them. After the crushing and sorting processing to the
cable and wire, can get the copper granue and alumina granule.
United Tech take the “ crush, sort, recycling” as the principle,
and prodcue the processing system according to the exact condition
and the final purpose. United Tech Machinery, one professional
crushing expert to meet your requirements to the CUSTOMIZED
SHREDDER.
Bulky waste furniture processing diagram:
Description:
This processing diagram is used for the cable and wire crushing and
sorting. It can be adjusted according to customers’ actual
condition.
The material is shredded by the shredder, the ouput size is less
than 50mm..After shredding, sort out the metals copper, alumina,
plastic, dust, etc.
Features:
The processing system is totally enclosed design, including
crushing, dedust, sorting, etc.
The core shredder with the welding alloy steel, strong wear
resistance, decrease the maintaince cost.
The blade is detachable design, spiral arragement, easier to catch
the materials to crush.
Brand plate speed reducer, low speed, large torque.
In contrast to high-speed systems, these shredders are particularly
resistant to foreign objects. If a cutting disc detects a foreign
object, the machine stops immediately. This prevents damage to the
cutting unit. In addition, the drive permits frequent reversing,
which is particularly beneficial when shredding problematic
materials. The integrated perforated screen quick replacement
system that comes standard permits the quick and efficient
replacement of the perforated screen.
The double shaft shredder allows the processing of a wide variety
of materials, dimensions and densities, being also suitable for the
reduction of bulky products. It is equipped with a large hopper and two shafts, which support
the cutting discs, being driven by two independent gear motors. The
cutting discs are manufactured in high quality steel and wear
resistant. The reduced speed of rotation allows low energy
consumption and noise level, keeping high productions. The shredder is equipped with an automatic
inversion system, powered in case of lock and resumption of
movement in order to ensure the continuity of production. As an
option, an upper ram can be mounted for processing of bulky parts
(bumpers, containers, etc.).
| Model | D32100 | D35120 | D35150 | D40150 | D40180 | D43150 | D43180 | D52120 | D52150 | D52180 | D62140 | D62180 | D62210 |
| Cutting Chamber size C/D (mm) | 650×1000 | 680×1200 | 680×1500 | 825×1500 | 825×1800 | 900×1500 | 900×1800 | 1100×1200 | 1100×1500 | 1100×1800 | 1300×1400 | 1300×1820 | 1300×2100 |
| Rotor Blade Diameter (mm) | 320 | 350 | 350 | 400 | 400 | 430 | 430 | 520 | 520 | 520 | 620 | 620 | 620 |
| Rotor Ratate Speed (r/min) | 10-15 | 10-15 | 10-15 | 10-15 | 10-15 | 10-15 | 10-15 | 10-15 | 10-15 | 10-15 | 10-15 | 10-15 | 10-15 |
| Rotor Blade Quantity (PCS) | 25 | 30 | 38 | 30 | 45 | 30 | 36 | 20 | 30 | 30 | 20 | 26 | 30 |
| Rotor Blade Thickness (mm) | 40 | 40 | 40 | 50 | 40 | 50 | 50 | 60 | 50 | 60 | 70 | 70 | 70 |
| Rotor Motor Power (KW) | 18.5+18.5 | 22+22 | 22+22 | 45+45 | 55+55 | 55+55 | 75+75 | 75+75 | 75+75 | 75+75 | 90+90 | 90+90 | 90+90 |
| Net Weight (kgs) | 5200 | 6000 | 6500 | 10000 | 12000 | 11000 | 13500 | 12000 | 14000 | 16000 | 15000 | 20000 | 24000 |
