Our granulator in good appearance, is welded by rigid steel
structure, machine case half -and -half opening, which makes
convenience to clean, remove knives and maintenance, blade roller
is to be chosen by different crushing material. Optional air
conveying collecting units and sound-proofed execution are at
user’s request.
Suitable for crushing materials as: plastic materials, rubber, PET
bottle, paper, cardboard, electronic board, thin film, sprue, pipe,
sheet, nylon, and plastic bottles, etc.
This Granulator is economical, practical, simple operation, durable
and so on.
| Model | G2140 | G2640 | G2660 | G3260 | G3280 |
| Overall Size L/W/H(mm) | 1250*790*1365 | 1491*1177*1625 | 1483*1377*1740 | 1486*1446*1786 | 1580*1633*1889 |
| Rotor Blade Diameter(mm) | 210 | 260 | 260 | 320 | 320 |
| Roller Length(mm) | 400 | 400 | 600 | 600 | 800 |
| Rotor Rotate Speed (r/min) | 540 | 607 | 607 | 592 | 592 |
| Screen Mesh(mm) | 8 | 8 | 8 | 12 | 12 |
| Rotor Blade Quantity (PCS) | 3*2 | 3*2 | 3*2 | 3*2 | 3*2 |
| Counter Quantity(PCS) | 2*2 | 2*2 | 2*2 | 1*1 | 2*2 |
| Rotor Motor Powder (KW) | 7.5 | 11 | 15 | 18.5 | 22 |
| Net Weight(KG) | 360 | 660 | 960 | 1470 | 1730 |
| | | | | |
| Model | G4280 | G42100 | G52100 | G52120 | G66120 |
| Overall Size L/W/H(mm) | 1770*1660*2500 | 1770*1899*2500 | 2119*2035*2984 | 2070*2251*2945 | 2435*2304*4339 |
| Rotor Blade Diameter(mm) | 420 | 420 | 520 | 520 | 660 |
| Roller Length(mm) | 800 | 1000 | 1000 | 1200 | 1200 |
| Rotor Rotate Speed (r/min) | 521 | 521 | 462 | 462 | 462 |
| Screen Mesh(mm) | 12 | 12 | 12 | 12 | 12 |
| Rotor Blade Quantity (PCS) | 3*2 | 3*2 | 5*2 | 5*2 | 5*2 |
| Counter Quantity(PCS) | 2*2 | 2*2 | 2*2/2*3 | 2*2/2*3 | 2*2/2*3 |
| Rotor Motor Powder (KW) | 37 | 45 | 55 | 75 | 90 |
| Net Weight(KG) | 2800 | 3230 | 4200 | 5500 | 7650 |
| | | | | |
| Model | G66160 | G80160 | G80200 | G80240 | |
| Overall Size L/W/H(mm) | 2360*2815*4344 | 2538*3180*4560 | 2735*3380*3475 | 2735*3580*4765 | |
| Rotor Blade Diameter(mm) | 660 | 800 | 800 | 800 | |
| Roller Length(mm) | 1600 | 1600 | 2000 | 2400 | |
| Rotor Rotate Speed (r/min) | 462 | 415 | 415 | 415 | |
| Screen Mesh(mm) | 12 | 12 | 12 | 12 | |
| Rotor Blade Quantity (PCS) | 5*2 | 5*2 | 5*2 | 5*2 | |
| Counter Quantity(PCS) | 4*2/4*3 | 4*2/4*3 | 4*2/4*3 | 4*2/4*3 | |
| Rotor Motor Powder (KW) | 132 | 160 | 200 | 250 | |
| Net Weight(KG) | 9720 | 11400 | 13600 | 15780 | |
Note:
1. The voltage about the power supply can be selected by the
customer’s specific requirements.
2. The granulator capacity can be influenced by the material
compostion and output size.
Zibo United Tech Machinery Co., Ltd.
What about the quality of your products?
1. we have a special training for each worker.
2. we use China famous brand spare parts to cast the machine.
3. have a trial test run before delivery the machine out of the
factory.
How about the shipping and package?
1. we arrange shipment usually according to your special
requirements.
2. Usually plywood package. Or according to clients's requirements.
How to get a suitable machine?
1. what is the raw material
2. the dimension of the input material and outpout material
3. the capacity,and power condition.
Tell me those data, we can help you choose the Waste type Shredder
for you.
Please feel free to contact me any time with any questions.
We are waiting for you!
Our service:
(1) Your inquiry related to our products or prices will be replied
in 12hours.
(2) Our engineer will make machine placement chart according to
client’s workshop chart
(3) We provide 12 months guarantee since the date of bill of
loading. All products are passed strict test.
