Double shaft shredder also known as shear type shredder , shredder
and through shear , extrusion can reduce the material size. The
shreddering machine widely used in the waste plastic , waste rubber
, wood and other waste.
Zibo United Tech Machinery Co., Ltd. has the technology which is
more mature and more advanced design of biaxial crusher series,
volume reduction processing provides reliable quality equipment for
pre crushing, utilization of waste recycling in china.
The machine is suitable to process very big size of waste
furniture, such as fiber board or shaving board (particleboard) in
furniture industry, timber harvesting, wood cutting remains (branc
hes), wood processing remains(saw mill residue), waste wood
pallets, and even other no wood material (reed, bamboo).
1. The machine with big feeding mouth, it can put the big plastic
product freely.
2. The rotary blade and cutting blade and blade edge with special
design, it can get very high efficiency and high capacity
3. The machine is control by PLC system, . The knife can rotated in
opposite direction, and also can close automatic if something
unexpected happen, with very high safety service
4. The machine running slowly with low noise and low dust
5. The knife material is high quality tool steel, with long
lifetime.
We specialize in this crusher and environment-protection field many
year. with best quality, best service and competitive price,
More service we can provide:
1. Customize & OEM is available.
2. Consumable parts for free distribution.
3. Our engineer are available to service oversea.
4. Professional Free Design
5. Respect clients; Devote ourselves to improving the total value
6. 12 months warranty
What about the quality of your products?
1. we have a special training for each worker.
2. we use China famous brand spare parts to cast the machine.
3. have a trial test run before delivery the machine out of the
factory.
How about the shipping and package?
1. we arrange shipment usually according to your special
requirements.
2. usually wooden case or plywood package.
How to get a suitable machine?
1. what is the raw material
2. the dimension of the input material and outpout material
3. the capacity,and power condition.
Tell me those data, we can help you choose the Waste type Shredder
for you.
Please feel free to contact me any time with any questions.
We are waiting for you!
Mode | D2830 | D2840 | D2860 | D2880 |
dimension L/W/H(mm) | 1450x1060x1850 | 1590x1060x1850 | 2560x1060x1850 | 2820x1060x1850 |
Cutting Chamber size C/D(mm) | 300x470 | 400x470 | 600x480 | 800x480 |
Rotor Blade Diameter(mm) | Φ280 | Φ280 | Φ280 | Φ280 |
Rotor Ratate Speed (r/min) | 14.2 | 14.2 | 14.2 | 14.2 |
Rotor Blade Quantity (PCS) | 15 | 20 | 30 | 40 |
Rotor Blade Thickness(mm) | 20 | 20 | 20 | 20 |
Rotor Motor Powder(KW) | 7.5 | 7.5 | 5.5+5.5 | 7.5+7.5 |
Net Weight(KG) | 1300 | 1450 | 2000 | 2200 |
|
|
|
|
|
Model | D3260 | D3280 | D4280 | D42100 |
dimension L/W/H(mm) | 2658x1366x1911 | 2930x1385x1927 | 2940x1816x2270 | 3275x1946x2275 |
Cutting Chamber size C/D(mm) | 610x580 | 890x580 | 890x736 | 1052x736 |
Rotor Blade Diameter(mm) | Φ320 | Φ320 | Φ430 | Φ430 |
Rotor Ratate Speed (r/min) | 14.2 | 14.2 | 14.8 | 14.8 |
Rotor Blade Quantity (PCS) | 20 | 22 | 22 | 26 |
Rotor Blade Thickness(mm) | 30 | 40 | 40 | 40 |
Rotor Motor Powder(KW) | 15 | 18.5 | 15+15 | 18.5+18.5 |
Net Weight(KG) | 2200 | 2400 | 3700 | 4100 |
|
|
|
|
|
Model | D42120 | D52100 | D52130 | D52160 |
dimension L/W/H(mm) | 3416x1946x2275 | 3334x1866x2670 | 3716x2234x2670 | 4016x2234x2670 |
Cutting Chamber size C/D(mm) | 1213x736 | 984x948 | 1324x948 | 1624x948 |
Rotor Blade Diameter(mm) | Φ430 | Φ514 | Φ514 | Φ514 |
Rotor Ratate Speed (r/min) | 14.8 | 11.8 | 11.8 | 11.8 |
Rotor Blade Quantity (PCS) | 30 | 20 | 26 | 32 |
Rotor Blade Thickness(mm) | 40 | 50 | 50 | 50 |
Rotor Motor Powder(KW) | 22+22 | 30+30 | 37+37 | 45+45 |
Net Weight(KG) | 4500 | 6500 | 8700 | 9200 |
Double Shaft Shredder Introduction:
Double shaft shredder have been designed for a wide array of
applications and industries,suitable for shredding solid material such as E-waste, metal, wood,
plastic, scrap tires, packaging barrel. Pallets, etc.And particularly well suited to the size reduction of bulky or
voluminous materials which could include contamination such as
metals or stones. Depending on input material and the following
process the shredded material can be used directly or go into the
next step of size reduction. It can efficient to increase the bulk
density and decrease the transportation cost.It is widely used in industry waste recycling, medical recycling,
electronic recycling, pallet recycling, municipal solid waste
recycling, plastic recycling, tire recycling, paper making
industry, etc.
Double Shaft Shredder has two rotors built into the machine that
rotate at low speeds, high torque and low noise. With the function
of Siemens microcomputer control system, it is possible to control
automatically start, stop. Automatic reverse sensors to protect the
machine against over loading and jamming.
Feature:
Shredding room is adopted large thickness, high strength, Wear
resistance of steel. The whole crushing room was finished by CNC
machine, with high precision, easy disassembly, repair,
maintenance, long life and other advantages.
The knives use imported high-quality alloy steel, with high
strength, good toughness, not easy to break and so on. And can to
ensure that there is a good blade in the work, disassembly, and
easy to maintenance.
Shaft is adopted a special material processed by CNC machine, with
high strength, good toughness, not easy to out of shape, work
status stable. Rotary blades can use integral blades or assemble
blades, blades structure can be divided into single claw blades,
double claw blades and multi-claw blades.
Rotary blades can cut material evenly, reduce energy consumption,
reduce noise, loading and unloading blades is very convenient.
