Waste Textile Shredder Applications:
Textile after shredded can be used for cleaning or as raw material
for further recycling. In that case, approximately 93% of all
textile waste diverted to recycling. Among this part, about 35% are
successfully reclaimed with going out as used clothing, 33% as
reprocessed fibers (filler in vehicle seats, upholstery,
insulation, etc), 25% is converted to cloth wipes and the left 7%
textile waste to landfill.
Zibo United Tech Machinery Co., Ltd.
Waste textile waste recycling industry is developping very fast
recently. Zibo United Tech Machinery Co., ltd. is the manufacture
of waste textile shredder, Our core strength lies as a shredder
machinery for solid wate reduction. We can offer you a textile
waste shredder to shred clothing, textile into smaller pieses.
We specialize in this crusher and environment-protection field many
year. with best quality, best service and competitive price.
Applications: textile, waste cloth and waste yarn, waste cotton clothing,
cotton, chemical fiber, flax, leather, plastic film, paper,
trademark, non-woven fabric, tire cord fabric, curtain, friction
cord, etc.
More service we can provide:
1. Customize & OEM is available.
2. Consumable parts for free distribution.
3. Our engineer are available to service oversea.
4. Professional Free Design
5. Respect clients; Devote ourselves to improving the total value
6. 12 months warranty
Feature of the textile shredder in Zibo United Tech Machinery Co., Ltd.
1.High efficiency, energy saving, environmental protection.
2. Product design advanced and reasonable structure.
3. The shear strength, discharging fine granularity.
4. Speed is low, stable and reliable use.
5. Discharging granularity is adjustable, wide application scope.
6. Bearing adopts 6 seal protection, long service life.
7. Shear plate wear small, long service life.
Double shaft shredder have been designed for a wide array of applications and
industries, suitable for shredding solid material such as E-waste,
metal, wood, plastic, scrap tires, packaging barrel. Pallets, etc.
And particularly well suited to the size reduction of bulky or
voluminous materials which could include contamination such as
metals or stones. Depending on input material and the following
process the shredded material can be used directly or go into the
next step of size reduction. It can efficient to increase the bulk
density and decrease the transportation cost. It is widely used in
industry waste recycling, medical recycling, electronic recycling,
pallet recycling, municipal solid waste recycling, plastic
recycling, tire recycling, paper making industry, etc.
Double Shaft Shredder has two rotors built into the machine that rotate at low speeds,
high torque and low noise. With the function of Siemens
microcomputer control system, it is possible to control
automatically start, stop. Automatic reverse sensors to protect the
machine against over loading and jamming.
| Mode | D2830 | D2840 | D2860 | D2880 |
| dimension L/W/H(mm) | 1450x1060x1850 | 1590x1060x1850 | 2560x1060x1850 | 2820x1060x1850 |
| Cutting Chamber size C/D(mm) | 300x470 | 400x470 | 600x480 | 800x480 |
| Rotor Blade Diameter(mm) | Φ280 | Φ280 | Φ280 | Φ280 |
| Rotor Ratate Speed (r/min) | 14.2 | 14.2 | 14.2 | 14.2 |
| Rotor Blade Quantity (PCS) | 15 | 20 | 30 | 40 |
| Rotor Blade Thickness(mm) | 20 | 20 | 20 | 20 |
| Rotor Motor Powder(KW) | 7.5 | 7.5 | 5.5+5.5 | 7.5+7.5 |
| Net Weight(KG) | 1300 | 1450 | 2000 | 2200 |
| | | | |
| Model | D3260 | D3280 | D4280 | D42100 |
| dimension L/W/H(mm) | 2658x1366x1911 | 2930x1385x1927 | 2940x1816x2270 | 3275x1946x2275 |
| Cutting Chamber size C/D(mm) | 610x580 | 890x580 | 890x736 | 1052x736 |
| Rotor Blade Diameter(mm) | Φ320 | Φ320 | Φ430 | Φ430 |
| Rotor Ratate Speed (r/min) | 14.2 | 14.2 | 14.8 | 14.8 |
| Rotor Blade Quantity (PCS) | 20 | 22 | 22 | 26 |
| Rotor Blade Thickness(mm) | 30 | 40 | 40 | 40 |
| Rotor Motor Powder(KW) | 15 | 18.5 | 15+15 | 18.5+18.5 |
| Net Weight(KG) | 2200 | 2400 | 3700 | 4100 |
| | | | |
| Model | D42120 | D52100 | D52130 | D52160 |
| dimension L/W/H(mm) | 3416x1946x2275 | 3334x1866x2670 | 3716x2234x2670 | 4016x2234x2670 |
| Cutting Chamber size C/D(mm) | 1213x736 | 984x948 | 1324x948 | 1624x948 |
| Rotor Blade Diameter(mm) | Φ430 | Φ514 | Φ514 | Φ514 |
| Rotor Ratate Speed (r/min) | 14.8 | 11.8 | 11.8 | 11.8 |
| Rotor Blade Quantity (PCS) | 30 | 20 | 26 | 32 |
| Rotor Blade Thickness(mm) | 40 | 50 | 50 | 50 |
| Rotor Motor Powder(KW) | 22+22 | 30+30 | 37+37 | 45+45 |
| Net Weight(KG) | 4500 | 6500 | 8700 | 9200 |
Note:
1. The voltage about the power supply can be selected by the
customer’s specific requirements.
2. The shredder capacity can be influenced by the material
compostion and output size.
Zibo United Tech Machinery Co., Ltd.
What about the quality of your products?
1. we have a special training for each worker.
2. we use China famous brand spare parts to cast the machine.
3. have a trial test run before delivery the machine out of the
factory.
How about the shipping and package?
1. we arrange shipment usually according to your special
requirements.
2. Usually plywood package. Or according to clients's requirements.
How to get a suitable machine?
1. what is the raw material
2. the dimension of the input material and outpout material
3. the capacity,and power condition.
Tell me those data, we can help you choose the Waste type Shredder
for you.
Please feel free to contact me any time with any questions.
We are waiting for you!
Our service:
(1) Your inquiry related to our products or prices will be replied
in 12hours.
(2) Our engineer will make machine placement chart according to
client’s workshop chart
(3) We provide 12 months guarantee since the date of bill of
loading. All products are passed strict test.
