Plastic Shredder
If you have plastic in various shapes and sizes and you need to
turn these scrap materials or components into a commodity that can
be recaptured for use in your manufacturing processes, then our
plastic shredder machines -Zibo United Tech Machinery Co., Ltd. are
what you need. It doesn't matter if it's small PET bottles, PVC,
vinyl, plastic containers, long strips, purgings or a host of other
sizes and configurations, getting it down to a manageable or
reusable size is one of the first steps in the reclamation and
recycling process. The equipment needed for this initial size
reduction varies depending upon the plastic being reclaimed.
No matter what your needs are for plastic shredding, we Zibo United
Tech Machinery Co., Ltd. Plastic Shredder can help you reclaim or process your plastic products or scrap and
turn it a valuable commodity.
Versatility.
Some plastic shredders lock you in to doing it only on way. Our shredders have dual hex
shafts and various knife designs that can be easily reconfigured to
alter the shredding process to yield any desired output. We offer a
large array of easy-to-install bed screens that can be used to
qualify the shred size if desired.
Double
Shaft Shredder has two rotors built into the machine that rotate at low speeds,
high torque and low noise. With the function of Siemens
microcomputer control system, it is possible to control
automatically start, stop. Automatic reverse sensors to protect the
machine against over loading and jamming.
Feature:
Shredding room is adopted large thickness, high strength, Wear
resistance of steel. The whole crushing room was finished by CNC
machine, with high precision, easy disassembly, repair,
maintenance, long life and other advantages.
The knives use imported high-quality alloy steel, with high
strength, good toughness, not easy to break and so on. And can to
ensure that there is a good blade in the work, disassembly, and
easy to maintenance.
Zibo United Tech Machinery Co., Ltd.
Shaft is adopted a special material processed by CNC machine, with
high strength, good toughness, not easy to out of shape, work
status stable. Rotary blades can use integral blades or assemble
blades, blades structure can be divided into single claw blades,
double claw blades and multi-claw blades.
Rotary blades can cut material evenly, reduce energy consumption,
reduce noise, loading and unloading blades is very convenient.
Our service:
(1) Your inquiry related to our products or prices will be replied
in 12hours.
(2) Our engineer will make machine placement chart according to
client’s workshop chart
(3) We provide 12 months guarantee since the date of bill of
loading. All products are passed strict test.
| Model | D2830 | D2840 | D2860 | D2880 | D3260 |
| dimension L/W/H(mm) | 1450x1060x1850 | 1590x1060x1850 | 2560x1060x1850 | 2820x1060x1850 | 2658x1366x1911 |
| Cutting Chamber size C/D(mm) | 300x470 | 400x470 | 600x480 | 800x480 | 610x580 |
| Rotor Blade Diameter(mm) | Φ280 | Φ280 | Φ280 | Φ280 | Φ320 |
| Rotor Ratate Speed (r/min) | 14.2 | 14.2 | 14.2 | 14.2 | 14.8 |
| Rotor Blade Quantity (PCS) | 15 | 20 | 20 | 20 | 15 |
| Rotor Blade Thickness(mm) | 20 | 20 | 30 | 40 | 40 |
| Rotor Motor Power(KW) | 7.5 | 5.5+5.5 | 7.5+7.5 | 11+11 | 15+15 |
| | | | | |
| Model | D3280 | D32100 | D32120 | D42100 | |
| dimension L/W/H(mm) | 2930x1385x1927 | 2930x1385x1927 | 3416x1946x2275 | 3275x1946x2275 | |
| Cutting Chamber size C/D(mm) | 890x580 | 1020x580 | 1213x736 | 1052x736 | |
| Rotor Blade Diameter(mm) | Φ320 | Φ320 | Φ320 | Φ430 | |
| Rotor Ratate Speed (r/min) | 14.8 | 14.8 | 14.8 | 9.2 | |
| Rotor Blade Quantity (PCS) | 22 | 25 | 30 | 20 | |
| Rotor Blade Thickness(mm) | 40 | 40 | 40 | 50 | |
| Rotor Motor Power(KW) | 18.5+18.5 | 22+22 | 30+30 | 30+30 | |
| | | | | |
| Model | D42120 | D42150 | D52120 | D52160 | |
| dimension L/W/H(mm) | 3416x1946x2275 | 3716x2234x2670 | 3716x2234x2670 | 4016x2234x2670 | |
| Cutting Chamber size C/D(mm) | 1213x736 | 1224x948 | 1224x948 | 1624x948 | |
| Rotor Blade Diameter(mm) | Φ430 | Φ516 | Φ516 | Φ516 | |
| Rotor Ratate Speed (r/min) | 8.2 | 8.2 | 9.2 | 9.21875 | |
| Rotor Blade Quantity (PCS) | 24 | 30 | 20 | 20+10 | |
| Rotor Blade Thickness(mm) | 50 | 50 | 60 | 60+40 | |
| Rotor Motor Power(KW) | 37+37 | 45+45 | 45+45 | 55+55 | |
Note:
1. The voltage about the power supply can be selected by the
customer’s specific requirements.
2. The shredder capacity can be influenced by the material
compostion and output size.
Zibo United Tech Machinery Co., Ltd.
What about the quality of your products?
1. we have a special training for each worker.
2. we use China famous brand spare parts to cast the machine.
3. have a trial test run before delivery the machine out of the
factory.
How about the shipping and package?
1. we arrange shipment usually according to your special
requirements.
2. Usually plywood package. Or according to clients's requirements.
How to get a suitable machine?
1. what is the raw material
2. the dimension of the input material and outpout material
3. the capacity,and power condition.
Tell me those data, we can help you choose the Waste type Shredder
for you.
Please feel free to contact me any time with any questions.
We are waiting for you!
